Router RUTX11

lei2,283.27
Tax included

Price excluding VAT: lei1,887.00

Delivery: 1- 2 days

In stock available in Iași, RO: 2 items

Router RUTX11

INDUSTRIAL CELLULAR ROUTER

Quantity
Last items in stock

This powerful LTE Cat 6 cellular router is designed for professional applications requiring reliable, fast connection and high data throughput. The RUTX11 is equipped with four Gigabit Ethernet ports, AC Wi-Fi, Bluetooth LE, and is EN 45545-2-certified, making it approved for use in passenger trains across Europe.

4G LTE CAT 6

  • Cellular speeds up to 300Mbps with Carrier Aggregation

DUAL SIM

  • With auto failover, backup WAN and other switching scenarios

WI-FI & BT

  • Wave-2 802.11ac Dual Band Wi-Fi and Bluetooth LE

GIGABIT ETH

  • 4 x Gigabit Ethernet ports with up to 128 port/tag-based VLANs supported

For more details, you can access : RUTX11 Gigabit Cellular Router

Network planning

Define which devices need wired connections and which will use Wi-Fi or Bluetooth LE before assigning the four Gigabit Ethernet ports. Where the installation uses VLANs, plan the port and tag assignments together with the connected equipment. Select the primary and backup network paths and test the dual-SIM switching scenario. The quoted cellular rate is a maximum; coverage and network conditions at the site should be assessed when estimating the capacity available to the application.

RUTX11
2 Items

Data sheet

Mobile module
4G LTE Cat 6 up to 300 DL/ 50 UL Mbps; 3G up to 42 DL/ 5.76 UL Mbps
eSIM
Consumer type eSIM, profile download and removal operations, up to 7 eSIM profiles; does not include data plans
SIM switch
Dual SIM and eSIM, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection
Wireless mode
802.11b/g/n/ac Wave 2 (Wi-Fi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO), 802.11r fast transition, Access Point (AP), Station (STA)
Wi-Fi users
Up to 150 simultaneous connections
Ethernet
WAN 1 x WAN port 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u, 802.3az standards , supports auto MDI/MDIX LAN 3 x LAN ports, 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX
Routing
Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing
Protocol
HTTP(S), MQTT, Azure MQTT
Supported modes
Station,Outstation
System Characteristics
CPU Quad-core ARM Cortex A7, 717 MHz RAM 256 MB, DDR3 FLASH storage 256 MB, SPI Flash
Connector
4-pin industrial DC power socket
Casing material
Aluminium housing
Dimensions (W x H x D)
115 x 44.2 x 95.1 mm
Weight
456 g
Mounting options
DIN rail, wall mount, flat surface (all require additional kit)
Operating temperature
-40 °C to 75 °C
Operating humidity
10% to 90% non-condensing
Ingress Protection Rating
IP30
Input/Output
Input 1 x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high Output 1 x Digital Output, Open collector output, max output 30 V, 300 mA
