INDUSTRIAL CELLULAR ROUTER RUT901

Name: INDUSTRIAL CELLULAR ROUTER RUT901
Brand: TELTONIKA
SKU: RUT901
Price: 953.6 RON
Availability: InStock

lei953.60

Tax included

Price excluding VAT: lei788.10

Delivery: 1- 2 days

In stock available in Iași, RO: 19 items

RUT901

INDUSTRIAL CELLULAR ROUTER

Connectivity and integration

The RUT901 industrial cellular router supports 4G LTE Cat 4, 3G and 2G connectivity. Dual SIM and automatic WAN failover provide options for switching to an available backup connection. The Wi-Fi access point includes Hotspot functionality, while supported protocols include MQTT, Modbus TCP and DNP3.

Planning the connection

Choose the mobile operator and data plan for the installation location, then check network availability before deployment. Configure the primary connection, backup connection and switching conditions to match the needs of the connected equipment. Failover depends on the availability and configuration of the backup path; it does not replace checking coverage and power supply conditions.

For integration with an existing monitoring system, identify the required protocol and configure the device and remote endpoint consistently. During commissioning, verify the transfer of the expected data and test the configured connection changeover. Record the configuration so that future maintenance can distinguish the router settings from changes to the mobile service or remote application.

Reference RUT901

In stock 27 Items

Data sheet

Input: 1 x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high
Output: 1 x Digital Output, Open collector output, max output 30 V, 300 mA
Mobile module: 4G LTE Cat 4 up to 150 DL/50 UL Mbps; 3G up to 21 DL/5.76 UL Mbps; 2G up to 236.8 DL/236.8 UL kbps
eSIM: Consumer type eSIM, profile download and removal operations, up to 7 eSIM profiles; does not include data plans
SIM switch: SIM and eSIM, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection
Wireless mode: 802.11b/g/n (Wi-Fi 4), Access Point (AP), Station (STA)
Wi-Fi security: WPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates, disable auto-reconnect, 802.11w Protected Management Frames (PMF)
Wi-Fi users: Up to 100 simultaneous connections
Ethernet: WAN 1 x WAN port 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u, 802.3az standards , supports auto MDI/MDIX LAN 3 x LAN ports, 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX
Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP()S, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN
Protocol: HTTP(S), MQTT, Azure MQTT
Supported modes: Station,Outstation
Connector: 4-pin industrial DC power socket
Casing material: Aluminium housing, plastic panels
Dimensions (W x H x D): 110 x 50 x 100 mm
Weight: 297 g
Mounting options: DIN rail, wall mount, flat surface (all require additional kit)
Operating temperature: -40 °C to 75 °C
Operating humidity: 10% to 90% non-condensing
Ingress Protection Rating: IP30
